Clopal Ceiling Mounted PIR Motion Sensor Switch | 360° Motion Detector | Adjustable Time & Lux | 220-240V AC

Upgrade your lighting with the Clopal Ceiling Mounted PIR Motion Sensor Switch, designed to provide automatic, energy-efficient lighting for homes, offices, hotels, and commercial spaces. Using advanced Passive Infrared (PIR) technology, the sensor detects human movement within a 360° detection area and automatically switches connected lights ON or OFF, improving convenience while reducing unnecessary power consumption.

The built-in adjustable LUX control allows you to choose whether the sensor operates only in low-light conditions or throughout the day and night. An adjustable time delay lets you customize how long the light remains ON after motion is detected. If movement continues, the timer automatically resets to keep the light ON.

Ideal for corridors, staircases, washrooms, parking areas, store rooms, lobbies, and entrances, the Clopal PIR Motion Sensor delivers reliable performance with simple ceiling installation.

Key Features

• 360° wide-angle PIR motion detection
• Up to 6-meter detection range
• Automatic ON/OFF lighting control
• Adjustable time delay (10 seconds to 7 minutes)
• Adjustable day/night (LUX) sensitivity
• Energy-saving automatic operation
• Detects human motion using infrared technology
• Low standby power consumption (Approx. 0.5W)
• Easy ceiling-mounted installation
• Suitable for residential and commercial applications

Technical Specifications

• Brand: Clopal
• Product Type: Ceiling Mounted PIR Motion Sensor Switch
• Operating Voltage: 220–240V AC
• Frequency: 50/60Hz
• Detection Angle: 360°
• Detection Distance: Up to 6m (Max)
• Installation Height: 2.2–4m
• Time Delay: Adjustable (10 sec ±3 sec to 7 min ±2 min)
• Ambient Light Control: Adjustable (<10–2000 Lux)
• Maximum Load:
  • Incandescent/Halogen: 1200W
  • LED Lighting: 300W
• Power Consumption: Approx. 0.5W
• Motion Detection Speed: 0.6–1.5m/s
• Working Temperature: -20°C to +40°C
• Working Humidity: <93% RH

Ideal Applications

• Homes
• Offices
• Hotels
• Staircases
• Corridors
• Washrooms
• Parking Areas
• Store Rooms
• Lobbies
• Hallways

Package Includes

• 1 × Clopal Ceiling Mounted PIR Motion Sensor Switch
• 1 × User Manual

This motion sensor is an excellent choice for anyone looking to enhance convenience, improve safety, and reduce electricity consumption through intelligent automatic lighting control.
